Logging Cable

  • Product Item：3
  • Logging Cable
  • Logging Cable
    • Logging Cable ESP system
    Inquiry Send Email

    Description

    What is Logging Cable?

    The Logging Cable is an integral and important part of the logging system that helps to suspend and hold the sonde in the length of borehole at the desired depth. Apart from it, logging cable is a system that uses cables to transport material from the woods to the landing surface. The logging cable acts as a conductor for electrical signals to and from the sonde to the surface. Furthermore, logging cable is a form of downhole cable which is used for monitoring well in the oil and gas sector. The logging cable is distributed over a measuring heave between the well and winch. Additionally, the material which is monitored by logging cable may be partially or fully suspended over the longer distance. Beside it, the logging cables are strung through stands in corridors. Moreover, logging cables are come up with different sizes and with large number of different rigging configuration that can be used in logging cable.
    Our main logging cable include W3BP Logging Cable,W4B Logging Cable,W7BPP Logging Cable.

    W3BP Logging Cable Parameters:

    Type Spec
    No. of cores X cross section
    mm2     		O.D and tolerance
    mm     		Conductor dia.
    No. X dia
    mm     		Nom.
    thickness of insulation
    mm     		Structure of steel wire Min.
    Bending dia
    mm     		High-temp
    resistant
    ℃     		Weight
    km/kg
    Inner layer Outer layer
    W3BP-5.60 3*0.24 5.60±0.10 7*0.21 0.26 12*0.79 18*0.79 320 150 135
    W3F46P-5.60 3*0.24 5.60±0.10 7*0.21 0.26 12*0.79 18*0.79 320 232 142
    W3BP-8.00 3*0.56 8.00±0.10 7*0.32 0.45 18*0.81 18*1.11 450 150 255
    W3F46P-8.00 3*0.56 8.00±0.10 7*0.32 0.45 18*0.81 18*1.11 450 232 265
    W3BP-11.80 3*1.00 8.00±0.10 7*0.43 1 24*1.00 24*1.26 500 150 500

    W3BP Logging Cable Performance:

    Type D.C resistance of conductor at 20℃
    No more than Ω/km     		Insulation
    MΩ.km
    resistance     		Cable withstands
    voltage
    VDC     		Capacitance
    Pf/m
    (1khz)     		Hight-temp-insulation resistance
    MΩ.km     		Elongation coefficient of cable
    m/km/5kN     		Rated breaking
    tension
    KN
    W3BP-5.60 75 500 1000 ≤ 170 150℃≥2.5 2.5 25
    W3F46P-5.60 75 500 1000 ≤ 170 200℃≥5.0 2.5 25
    W3BP-8.00 33 15000 1000 ≤ 175 150℃≥2.5 1.4 45
    W3F46P-8.00 33 15000 1000 ≤ 170 200℃≥5.0 1.4 45
    W3BP-11.80 18.1 15000 15000 ≤ 140 150℃≥2.5 0.8 80

    W4BP Logging Cable Parameters:

    Type Spec
    No. of cores X cross section
    mm2     		O.D and tolerance
    mm     		Conductor dia.
    No. X dia
    mm     		Nom.
    thickness of insulation
    mm     		Structure of steel wire Min.
    Bending dia
    mm     		High-temp
    resistant
    ℃     		Weight
    km/kg
    Inner layer Outer layer
    W4B-4.70 4*0.22 4.70±0.10 7*0.20 0.19 18*0.47 18*0.64 250 150 85
    W4BP-5.60 4*0.22 5.60±0.10 7*0.20 0.19 12*0.79 18*0.79 320 150 142
    W4F46P-5.60 4*0.22 5.60±0.10 7*0.20 0.19 12*0.79 18*0.79 320 232 145
    W4BP-8.00 4*0.56 8.00±0.10 7*0.32 0.38 18*0.81 18*1.11 450 150 255
    W4F46P-8.00 4*0.56 8.00±0.10 7*0.32 0.38 18*0.81 18*1.11 450 232 265

    W4B Logging Cable Performance:

    Type D.C resistance of conductor at 20℃
    No more than Ω/km     		Insulation
    MΩ.km
    resistance     		Cable withstands
    voltage
    VDC     		Capacitance
    Pf/m
    (1khz)     		Hight-temp-insulation resistance
    MΩ.km     		Elongation coefficient of cable
    m/km/5kN     		Rated breaking
    tension
    KN
    W4B-4.70 84.3 500 1000 ≤ 190 150℃≥2.5 4.5 13
    W4BP-5.60 84.3 500 1000 ≤ 150 150℃≥2.5 2.5 25
    W4F46P-5.60 84.3 500 1000 ≤ 175 200℃≥5.0 2.5 25
    W4BP-8.00 33 15000 1000 ≤ 195 150℃≥2.5 1.4 45
    W4F46P-8.00 33 15000 1000 ≤ 190 200℃≥5.0 1.4 45

    W7BPP Logging Cable Parameters:

    Type Spec
    No. of cores X cross section
    mm2     		O.D and tolerance
    mm     		Conductor dia.
    No. X dia
    mm     		Nom.
    thickness of insulation
    mm     		Structure of steel wire Min.
    Bending dia
    mm     		High-temp
    resistant
    ℃     		Weight
    km/kg
    W7B-6.4 7*0.24 6.40±0.10 7*0.21 0.25 18*0.63 18*0.89 350 150 160
    W7BP-11.8 7*0.56 11.80±0.10 7*0.32 0.72 24*1.00 24*1.26 500 150 498
    W7BPP-11.8 502
    W7BP-12.6 7*0.56 12.60±0.10 7*0.32 0.87 26*1.00 25*1.26 500 232 519
    W7BPP-12.6 521
    W7BP-13.2 7*0.56 13.20±0.10 7*0.32 0.72 17*1.47 23*1.47 600 150 650
    W7BPP-13.2 655
    W7F46P-11.8 7*0.56 11.80±0.10 7*0.32 0.72 24*1.00 24*1.26 500 232 502
    W7F46PP-11.8 504
    W7F46P-12.6 7*0.56 12.60±0.10 7*0.32 0.87 26*1.00 25*1.26 500 232 528
    W7F46PP-12.6 530
    W7F46P-13.2 7*0.56 13.20±0.10 7*0.32 0.72 17*1.47 23*1.47 600 232 651
    W7F46PP-13.2 656
    FL-W7F46PP-11.8 7*0.56 11.80±0.10 7*0.32 0.72 24*1.00 24*1.26 500 232 504

    W7BPP Logging Cable Performance:

    Type D.C resistance of conductor at 20℃
    No more than Ω/km     		Insulation
    MΩ.km
    resistance     		Cable withstands
    voltage
    VDC     		Capacitance
    Pf/m
    (1khz)     		Hight-temp-insulation resistance
    MΩ.km     		Elongation coefficient of cable
    m/km/5kN     		Rated breaking
    tension
    KN
    W7B-6.4 84.3 500 1000 ≤ 130 150℃≥2.5 2.85 80
    W7BP-11.8 33 15000 1200 ≤ 140 150℃≥2.5 0.8 80
    W7BPP-11.8
    W7BP-12.6 33 15000 1200 ≤ 135 150℃≥2.5 0.8 85
    W7BPP-12.6
    W7BP-13.2 33 15000 1200 ≤ 140 150℃≥2.5 0.9 85
    W7BPP-13.2
    W7F46P-11.8 33 15000 1200 ≤ 130 200℃≥5 0.8 85
    W7F46PP-11.8
    W7F46P-12.6 33 15000 1200 ≤ 120 200℃≥5 0.8 85
    W7F46PP-12.6
    W7F46P-13.2 33 15000 1200 ≤ 130 200℃≥5 0.9 85
    W7F46PP-13.2
    FL-W7F46PP-11.8 33 15000 1200 ≤ 130 200℃≥5 0.8 85

    Monoconductor Logging Cable

    Cable Type Nominal Diameter Max. Temp. F Breaking Strength (lbs)
    1N22WG 7/32 600 5,600
    1Q25YZ-FO   1/4 500 6,600
    1Q25YZ-FO-S75   1/4 500 5900
    1N32PP-EEHS   5/16 300 14,750
    1N32PTZ-EEHS   5/16 500 14,750
    1N32YZ-FO   5/16 500 12,000
    1N32WG   5/16 600 12,000
    1Q36PTZ-EHStZ4 0.359 400 9000
    1Q36YZ-FO-S77 0.36 500 10,100
    1Q36YZ-FO-S75 0.36 500 10,200
    1Q36YZ-FO 0.36 500 13,100
    2Q37CTZZ-EHStZZ 0.374 400 8200
    1N10RP 1/10 300 1,000
    1N12RP  1/8 300 1,600
    1N12RZ  1/8 500 1,600
    1L18RP   3/16 300 4,000
    1L18RZ   3/16 500 4,000
    1K22PP 7/32 300 5,600
    1K22PXZ 7/32 420 5,600
    1K22PTZ 7/32 500 5,600
    1K22SA-S75 7/32 500 4,700
    1K22SA-S77 7/32 500 4,900
    1K22SA–MP-35N 7/32 500 5,200
    1N22PP 7/32 300 5,600
    1N22PXZ 7/32 420 5,600
    1N22PTZ 7/32 500 5,600
    1N22SA–S75 7/32 500 4,700
    1N22SA–S77 7/32 500 4,900
    1N22SA-MP35N 7/32 500 5,200
    1N29PTZ-EEHS 9/32 500 10,900
    1N25PP  1/4 300 7,300
    1N25PXZ  1/4 420 7,300
    1N25PTZ  1/4 500 7,000
    1N25WA–S75  1/4 500 6,200
    1N25WA–S77  1/4 500 6,500
    1N29PP-EHS 9/32 300 10,200
    1N29PXZ-EHS 9/32 420 10,200
    1N29PTZ– EHS 9/32 500 10,200
    1N29WTZ–S75 9/32 500 7,800
    1N29WTZ–S77 9/32 500 8,200
    1N32PP   5/16 300 12,000
    1N32PXZ   5/16 420 12,000
    1N32PTZ   5/16 500 12,000
    1N32PTZ-LR   5/16 500 12,000
    1N32WTZ–S75   5/16 500 9,700
    1N32WTZ-S77   5/16 500 10,000
    1N42PTZ-LR   7/16 500 19,500
