Description
1.XSL-Swivel with spinner is a combination of swivel and Kelly spinner, driven by air Motor or hydraulic Motor, with keyless connection adopted between spinner and central pipe of swivel .
2.It is designed and manufactured according to API spec8 A"Specification for drilling and production hoisting equipment"
Welcome to consult, we will provide the most comprehensive technical support!
|
Model |
XSL135 |
XSL170 |
XSL225 |
XSL315 |
XSL450 |
|
|
Max static load |
KN |
1350 |
1700 |
2250 |
3150 |
4500 |
|
US ton |
150 |
180 |
250 |
350 |
500 |
|
|
Rated work load |
Kn |
1000 |
1300 |
1600 |
2200 |
3200 |
|
US ton |
110 |
145 |
175 |
245 |
350 |
|
|
Max speed |
rpm |
300 |
300 |
300 |
300 |
300 |
|
Mad working pressure |
Mpa |
35 |
35 |
35 |
35 |
35 |
|
Psi |
5000 |
5000 |
5000 |
5000 |
5000 |
|
|
Thread of drilling hose |
|
4LP |
4LP |
4LP |
4LP |
4LP |
|
Thread below sub |
|
6-5/8"reg LH |
6-5/8"reg LH |
6-5/8"reg LH |
6-5/8"reg LH |
6-5/8"reg LH |
|
Overall dimensions |
cm |
234*68*59 |
293*79*66 |
326*98*78 |
345*110*83 |
345*110*83 |
|
in |
92*27*23 |
115*31*26 |
129*39*31 |
136*43*33 |
136*43*33 |
|
|
Weight |
kg |
1718 |
2000 |
2772 |
2972 |
2972 |
|
ib |
3997.6 |
4409 |
6111 |
6550 |
6550 |
|
Our cutting-edge swivel comes in two distinct varieties: the classic common swivel and the innovative double duty swivel. The double duty swivel seamlessly integrates the conventional swivel with a spinner for enhanced functionality. The robust common swivel boasts essential components such as swivel bail, shell, support, gooseneck, central pipe, master bearing, joint, and more. Designed for precision, the lower end connects effortlessly with the kelly stem through REG thread. The swivel bail elegantly suspends from the hook, while the gooseneck and rotary hose offer versatile connectivity through REG thread or union connection.
Series of Swivel
| Model | SL135 | SL160 | SL170 | SL225 | SL315 | SL450 | |
| Max. Static Load | kN | 1350 | 1600 | 1700 | 2250 | 3150 | 4500 |
| Uston | 150 | 180 | 190 | 250 | 350 | 500 | |
| Dynamic Load Rating | kN | 1000 | 1200 | 1300 | 1600 | 2200 | 3200 |
| Uston | 110 | 135 | 145 | 180 | 250 | 360 | |
| Max. Speed | rpm | 300 | 300 | 300 | 300 | 300 | 300 |
| Mpa | 35 | 35 | 35 | 35 | 35 | 35 | |
| Max. Pressure | psi | 5000 | 5000 | 5000 | 5000 | 5000 | 5000 |
| mm | 64 | 64 | 64 | 75 | 75 | 75 | |
| Bore Size of Central Pipe | in | 2.52 | 2.52 | 2.52 | 3 | 3 | 3 |
| Thread of Drilling Hose | 4LP | 4LP | 4LP | 4LP | 4LP | 4LP | |
| Sub Connection | 65/8REG-LH | 65/8REG-LH | 65/8REG-LH | 65/8REG-LH | 65/8REG-LH | 65/8REG-LH | |
| Size | mm | 2280*680*590 | 2280*680*590 | 2550*820*835 | 2800*980*790 | 3015*1096*830 | 3015*1096*830 |
| in | 90*27*33 | 90*27*33 | 100*32*33 | 110*39*31 | 119*43*33 | 119*43*33 | |
| Weight | kg | 1500 | 1500 | 1782 | 2500 | 2700 | 2700 |
| lb | 3307 | 3307 | 3928 | 5512 | 5950 | 5950 |
Series of Swivel with Spinner
| Model | XSL135 | XSL160 | XSL170 | XSL225 | XSL315 | XSL450 | |
| Size | mm | 2340*790*660 | 2340*790*660 | 2926*820*835 | 3137*1096*830 | 3450*1096*830 | 3450*1096*830 |
| in | 92*31*26 | 92*31*26 | 115*32*33 | 123.5*43*33 | 136*43*33 | 136*43*33 | |
| Weight | kg | 1718 | 1718 | 2000 | 2772 | 2972 | 2972 |
| lb | 3779.6 | 3779.6 | 4409 | 6111 | 6550 | 6550 | |
