Description
This is a professional marine electric winch for offshore platforms,,DJFY-150×5 electric winch is themarine three speed Motor powered by gear drive drum winch device to realize the traction and lifting weights. It has the advantages of compact structure, convenient operation, safe and reliable operation, simple maintenance, stable operation and other advantages.
Winch design characteristics
When all bearings are rolling bearings and bearings.Shaft materials are alloy steel.The chain of forced lubrication.
Low drum slot.Roller with high and low end ventilation type pneumatic clutch.
The brake wheel network using circulating water forced cooling, intermediate frequency quenching on the surface, good abrasion resistance, long service life.
Low sprocket tooth profile by the intermediate frequency quenching.All transmission clutches are of involute spline gear clutch.
Low main brake use tape or disk.Auxiliary brake with electromagnetic eddy current brake or EATON brake.
Mechanical drive winch basic parameters
|
项目 |
参数 |
Item |
Specification |
|
电机功率kW |
22 |
Power（H.P） |
30 |
|
最大拉力kN |
150 |
Max lifting force(lb) |
33750 |
|
最大绳速m/min |
5 |
Max speed(ft/s) |
0.28 |
|
钢丝绳直径mm |
φ28 |
Rope diameter(in) |
φ1.1 |
|
卷筒容绳量m |
100 |
Rope capacity(ft) |
330 |
|
外形尺寸（长×宽×高mm） |
1700×1800×1200 |
Overall diamension(L×W×H)in |
67×71×47 |
