sand pump centrifugal pump
sand pump centrifugal pump
centrifugal pump is used for pumping drilling fluids, used as injection pumps for desander and desilter, or together with mud hopper for preparing solutions, or as a booster pump for Mud Pump. It uses a mechanical seal. All models of fengliang petroleum machinery Co.,Ltd centrifugal pumps use mechanical seals made of tungsten carbide, as well as highly reliable bearing units from well-known manufacturers. All spare parts are interchangeable with Mission Magnum, which makes it easier for customers to find the necessary spare parts. Open impeller pump design reduces axial loads and simplifies installation, repair and maintenance.
| Model |
Flow, m3/h |
Lift, m | Motor, kW |
Speed, RPM |
Impeller, Inch |
Weight, kg |
Dimensions LxWxH, mm |
| KWSB8×6-14 | 320 | 35 | 75 | 1450 | 14 | 1096 | 1968x650x1017 |
| KWSB8×6-12 | 1750 | 12 | |||||
| KWSB8×6-13 | 272 | 35 | 55 | 1450 | 13 | 987 | 1894x650x957 |
| KWSB8×6-11 | 1750 | 11 | |||||
| KWSB6×5-13 | 200 | 35 | 45 | 1450 | 13 | 786 | 1811x558x858 |
| KWSB6×5-10 | 1750 | 10 | |||||
| KWSB6×5-12 | 150 | 30 | 37 | 1450 | 12 | 771 | 1786x558x858 |
| KWSB6×5-9.5 | 1750 | 9.5 | |||||
| KWSB5×4-13 | 120 | 35 | 30 | 1450 | 13 | 696 | 1696x568x805 |
| KWSB5×4-11 | 1750 | 11 | |||||
| KWSB5×4-12 | 90 | 30 | 22 | 1450 | 12 | 583 | 1648x568x800 |
| KWSB5×4-10 | 1750 | 10 | |||||
| KWSB4×3-13 | 65 | 35 | 18.5 | 1450 | 13 | 561 | 1595x505x800 |
| KWSB4×3-12 | 1750 | 12 | |||||
| KWSB4×3-12 | 55 | 28 | 15 | 1450 | 12 | 482 | 1550x505x755 |
| KWSB4×3-10 | 1750 | 10 | |||||
| KWSB4×3-11 | 45 | 25 | 11 | 1450 | 11 | 464 | 1510x505x755 |
| KWSB4×3-9.5 | 1750 | 9.5 |
1. All spare parts interchangeable with most of the international Brand pump which helps customer to source spare parts easily
2. Thick, Strong Concentric casing provides extended life over conventional volute designs. The Concentric design minimizes turbulence and abrasive wear.
3. Wide open-vane impeller creates lower axial thrust for improved bearing life.
4. Pump casing made from hard ductile iron alloy, increased abrasion resistant capability compared to competitors pump.
5. Replaceable shaft sleeve prevents shaft wear.
6. Pump impeller made from hard ductile iron alloy, extended life over competitors design.
7. Anti-loosening impeller lock bolt to eliminate pump damage in case of improper Motor hook-up.
8. Compliance with standards: Ex/API/ISO/EAC.
9. High quality no-adjustment mechanical seal to provide zero leakage and longer operation life.
10. All bearings from top brand for reliable operation.
