hydraulic quad ram preventer BOP
API 3"~3 1/8", 10000Psi Hydraulic Quad Ram BOP
This Pressure Control Equipment is designed to apply to seal the wellhead in the coiled tubing working, so as to prevent the blow out accidents. During the operation, not pulling up the coiled tubing can replace the tubing. The rams can be opened and closed by hydraulic control, seal the wellhead in downhole with tubing inside, shear the tubing to seal the wellhead in the emergency. This Ram BOP owns the advantages of simple structures, convenient usage, easy operation, small volume, light weight, high load etc. With the anti-H2S design it is the ideal equipment in the oil field safety civilization operation.
Hydraulic Quad Ram BOP could be used for sealing well (tubing inside). It could seal well when cutting off tubing in emergency.Ram arrangement from top to bottomis Blind Ram, Shear Ram, Slip Ram, Pipe Ram.
|
Specification
|
ID (mm)
|
Working Pressure (Mpa)
|
Seal Tubing Diameter
|
Service Environment
|
Temperature Rating
|
Connection Manner
|
|
4FZ6-35
|
65
|
35
|
1''~ 1 1/2''
|
crude oil, natural gas,water with H2S and CO2
|
T20 (-29ºC~ +121ºC)
|
Flange or Union Thread
|
|
4FZ6-70
|
65
|
70
|
||||
|
4FZ6-105
|
65
|
105
|
||||
|
4FZ7-35
|
78
|
35
|
1 1/4''~1 3/4''
|
|||
|
4FZ7-70
|
78
|
70
|
||||
|
4FZ7-105
|
78
|
105
|
||||
|
4FZ10-70
|
103
|
70
|
1 1/2''~2''
|
|||
|
4FZ10-105
|
103
|
105
|
||||
|
4FZ13-70
|
130
|
70
|
1 1/2''~2 3/8''
|
|||
|
4FZ13-105
|
130
|
105
|
